Gravel Stabilizer Grids

Finished gravel driveway stabilized with a ground grid

Panels & Rolls · 3″ to 8″

Gravel Stabilizer Grids

Confine The Gravel. Stop The Migration.

Loose aggregate spreads sideways under load and sinks into the subgrade. A stabilizer grid holds each pocket of stone in place, so the surface stays where you put it.

  • Panel geocell or roll-form paver
  • Less base depth than loose gravel
  • Free shipping on every order
Shop stabilizer grids
  • 2Systems — panel & roll
  • 3–8inGeocell depth options
  • 577ft²Largest single unit

Choose Your System

Gravel Stabilizer Grids For Driveways, Roads And Parking

Gravel stabilizer grids solve the problem every gravel surface eventually has. Loose aggregate has no lateral restraint, so under a wheel it shoves sideways and downward — ruts form in the tracks, berms build at the edges, potholes open up, and every year or two you top the whole thing up again. A grid gives the stone somewhere to be. Confined in a cell or a pocket, the aggregate can no longer migrate, and a loose layer starts behaving like a single stiff surface that spreads load rather than concentrating it.

Two consequences follow. The surface stops rutting and needs far less topping up, and because the confined layer distributes load properly you generally need less depth of base material than the same job would take in loose gravel — which often pays for the grid on the aggregate saving alone.

We stock two systems. Geocell panels expand into a honeycomb and come in depths from 3″ to 8″, so you match confinement depth to the load. Roll-form gravel pavers unroll across large areas fast, sit in a shallow profile, are plowable, and come in four colors so the paver disappears into the aggregate. The comparison below sets out which suits which job.

Original price $374.81 - Original price $374.81
Original price
$374.81
$374.81 - $374.81
Current price $374.81

Cell-Tek Geocell Gravel Grid - LSG-6 (8' x 22.5' x 6")

Cell-Tek · LSG Series Load Support Grid · Model LSG-6 Cell-Tek LSG-6 is the deepest grid in the LSG Series at 6", rated to H20 loa...

View full details
Original price $374.81 - Original price $374.81
Original price
$374.81
$374.81 - $374.81
Current price $374.81
Original price $253.91 - Original price $253.91
Original price
$253.91
$253.91 - $253.91
Current price $253.91

Cell-Tek Geocell Gravel Grid - LSG-3 (8' x 22.5' x 3")

Cell-Tek · LSG Series Load Support Grid · Model LSG-3 Cell-Tek LSG-3 is the 3" deep grid in the LSG Series — the one to specify fo...

View full details
Original price $253.91 - Original price $253.91
Original price
$253.91
$253.91 - $253.91
Current price $253.91
Original price $296.50 - Original price $296.50
Original price
$296.50
$296.50 - $296.50
Current price $296.50

Cell-Tek Geocell Gravel Grid - LSG-4 (8' x 22.5' x 4")

Cell-Tek · LSG Series Load Support Grid · Model LSG-4 Cell-Tek LSG-4 is the 4" deep grid in the LSG Series, rated to H10 loading a...

View full details
Original price $296.50 - Original price $296.50
Original price
$296.50
$296.50 - $296.50
Current price $296.50
Original price $213.26 - Original price $213.26
Original price
$213.26
$213.26 - $213.26
Current price $213.26

EnviroGrid Geocell Ground Grid Paver - EGA20-3 (8.4' x 21.4' x 3")

EnviroGrid · Geocell Ground Grid · Model EGA20-3 EnviroGrid EGA20-3 is the 3" deep panel in the EGA20 range — the one for ligh...

View full details
Original price $213.26 - Original price $213.26
Original price
$213.26
$213.26 - $213.26
Current price $213.26
Original price $249.01 - Original price $249.01
Original price
$249.01
$249.01 - $249.01
Current price $249.01

EnviroGrid Geocell Ground Grid Paver - EGA20-4 (8.4' x 21.4' x 4")

EnviroGrid · Geocell Ground Grid · Model EGA20-4 EnviroGrid EGA20-4 is the 4" deep panel, rated at 40,000 lbs with gravel infi...

View full details
Original price $249.01 - Original price $249.01
Original price
$249.01
$249.01 - $249.01
Current price $249.01
Original price $316.48 - Original price $316.48
Original price
$316.48
$316.48 - $316.48
Current price $316.48

EnviroGrid Geocell Ground Grid Paver - EGA20-6 (8.4' x 21.4' x 6")

EnviroGrid · Geocell Ground Grid · Model EGA20-6 EnviroGrid EGA20-6 is the 6" deep panel, rated at 60,000 lbs with gravel infi...

View full details
Original price $316.48 - Original price $316.48
Original price
$316.48
$316.48 - $316.48
Current price $316.48
Original price $421.98 - Original price $421.98
Original price
$421.98
$421.98 - $421.98
Current price $421.98

EnviroGrid Geocell Ground Grid Paver - EGA20-8 (8.4' x 21.4' x 8")

EnviroGrid · Geocell Ground Grid · Model EGA20-8 EnviroGrid EGA20-8 is the deepest panel in the EGA20 range at 8". Geo Product...

View full details
Original price $421.98 - Original price $421.98
Original price
$421.98
$421.98 - $421.98
Current price $421.98
Original price $2,472.14 - Original price $2,472.14
Original price
$2,472.14
$2,472.14 - $2,472.14
Current price $2,472.14

NDS EZ Roll Gravel Pavers - GP4X150 - 4' x 150' Roll - Black

NDS · EZ Roll Gravel Pavers · Model GP4X150 NDS EZ Roll Gravel Pavers stop a gravel surface from rutting, spreading and washing away. Hexagonal ...

View full details
Original price $2,472.14 - Original price $2,472.14
Original price
$2,472.14
$2,472.14 - $2,472.14
Current price $2,472.14
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14

NDS EZ Roll Gravel Pavers - GP4X150G - 4' x 150' Roll - Gray

NDS · EZ Roll Gravel Pavers · Model GP4X150G Most crushed stone sold in North America is gray — limestone, granite, trap rock — and GP4X150G is ...

View full details
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14

NDS EZ Roll Gravel Pavers - GP4X150R - 4' x 150' Roll - Red

NDS · EZ Roll Gravel Pavers · Model GP4X150R Red rock, brick chip and rust-toned decorative aggregate get chosen for how they look, which makes ...

View full details
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14

NDS EZ Roll Gravel Pavers - GP4X150T - 4' x 150' Roll - Tan

NDS · EZ Roll Gravel Pavers · Model GP4X150T Buff gravel, decomposed granite and pea gravel all read warm, and a dark grid showing through them ...

View full details
Original price $2,547.14 - Original price $2,547.14
Original price
$2,547.14
$2,547.14 - $2,547.14
Current price $2,547.14

The Decision

Panel Geocell Or Roll-Form Paver?

Both confine aggregate so it cannot migrate. They differ in how deep the confinement goes and how quickly they install, and that is what should decide it.

Geocell panels

Expandable honeycomb, 3″ to 8″ deep

  • Depth is selectable. Match confinement depth to the load rather than accepting one profile.
  • Deeper cells carry more. The 6″ and 8″ depths suit heavy vehicles, machinery and access roads.
  • Works on slopes. Cell walls resist aggregate sliding downhill.
  • Cuts base depth. A confined layer spreads load, so less imported aggregate below.

Best for driveways and access roads carrying real weight, soft subgrade, slopes, and anywhere a deep confined layer is the point.

Roll-form gravel pavers

4′ × 150′ rolls, shallow profile

  • Fast over area. 577 sq ft per roll, unrolled rather than placed panel by panel.
  • Shallow profile. Sits close to the surface, so less excavation to begin with.
  • Plowable. A blade can clear it in winter without tearing the surface up.
  • Four colors. Black, gray, red and tan, so the paver reads as part of the aggregate.

Best for large residential driveways, paths and parking where the loads are cars and light trucks and install speed matters.

Both systems are available here. If you are unsure, the deciding questions are what is driving on it, how soft the ground underneath is, and whether the surface has to be plowed. Call (800) 524-4161 with those three and we will point you at the right one.

What We Stock

EnviroGrid geocell ground grid panel
Geocell panels · four depths

EnviroGrid Geocell

8.4′ × 21.4′ panels — 179.76 sq ft

100% virgin HDPE with a 10-year warranty, made in the USA. The widest depth range we carry, so it covers everything from light gravel drives up to machinery access.

Cell-Tek geocell gravel grid panel
Geocell panels · three depths

Cell-Tek Geocell

8′ × 22.5′ panels — 180 sq ft

Virgin HDPE in green, with accessory J-hooks, fabric and anchors available. A slightly larger panel footprint than EnviroGrid at the same depths.

NDS EZ Roll gravel paver roll
Roll form · four colors

NDS EZ Roll Gravel Pavers

4′ × 150′ rolls — 577 sq ft

Geotextile bonded to the underside, stakes included, plowable, and ADA tested to ASTM F1951-08. Rated H-20/H-25 with a 25-year life.

Choosing A Geocell Depth

With panel geocell, depth is the decision. Every depth uses the same material and installs the same way — a deeper cell simply confines more aggregate and spreads load across a wider footprint.

DepthTypical useEnviroGridCell-Tek
3″Light duty gravel, footpaths, garden accessEGA20-3LSG-3
4″The depth most residential gravel drives land onEGA20-4LSG-4
6″Heavier vehicles, access roads, softer subgradeEGA20-6LSG-6
8″Machinery, deep confinement, worst-case groundEGA20-8

Cell-Tek runs to 6″; if you need 8″ the EnviroGrid EGA20-8 is the panel to specify. Both are virgin HDPE and install identically.

Where Stabilizer Grids Get Used

Gravel drivewaysThe most common job — stops rutting and annual topping up.
Parking areasCommercial and overflow parking on aggregate.
Access & haul roadsSite roads over ground that would otherwise rut out.
Slopes & embankmentsCell walls stop aggregate sliding downhill.
RV & trailer padsLong-term parking where load sits in one place.
Paths & walkwaysFirm, wheel-friendly gravel that does not scatter.
Yards & laydown areasStorage and equipment areas that must stay level.
Around outbuildingsBarn, stable and shed approaches that turn to mud.

How Confinement Works

Loose gravel fails because nothing stops it moving sideways. A wheel pushes down, the stone under it displaces outward, and the wheel sinks into the space left behind. Repeat that a few hundred times and you have a rut with berms either side.

A stabilizer grid removes the sideways escape route. Each cell or pocket holds its aggregate captive, so a load arriving at one point is carried by the confined mass around it rather than displacing it. The practical effects:

  • No more rutting or potholes in the wheel tracks
  • No migration of stone to the edges or into the subgrade
  • Less base depth needed, because the confined layer spreads load properly
  • Water still drains through — the surface stays permeable
  • Far less topping up, which is where the running cost goes
Gravel being spread into a ground grid during installation
Aggregate spread into the grid, filling and slightly over-filling each cell.

Installation In Outline

Both systems follow the same broad sequence. Full step-by-step instructions and downloads are on each product page.

  1. 1
    Excavate and grade

    Strip to the required depth and grade the subgrade level. Because the confined layer carries load better, this is usually shallower than the same job in loose gravel.

  2. 2
    Lay separation fabric if required

    On soft or fine-grained subgrade, a geotextile below keeps fines migrating up into the aggregate. The roll-form pavers have fabric bonded on already.

  3. 3
    Place and anchor the grid

    Expand geocell panels and stake them; unroll roll-form pavers and stake at the specified spacing. Panels connect edge to edge for continuous coverage.

  4. 4
    Fill with aggregate

    Spread stone into the cells, working from one side over material already placed rather than driving on bare grid. Fill each cell and slightly over-fill.

  5. 5
    Compact and top off

    Compact the filled surface, then top off so a thin layer of aggregate covers the grid. Once covered, the grid is invisible and the surface reads as gravel.

Aggregate choice matters

Use angular crushed stone rather than rounded pea gravel wherever you can. Angular material interlocks and stays confined; rounded stone behaves like ball bearings and works its way loose regardless of what is holding it.

Why Buy Gravel Stabilizer Grids From Landscape Discount

Virgin material, not regrindThe geocell we stock is virgin HDPE from established US manufacturers, warrantied and specified.
Both systems stockedPanels and rolls, so the recommendation suits the job rather than what we happen to hold.
Free shipping, every orderOn every depth, every color and every quantity.
We answer the phoneA live person on (800) 524-4161, Monday to Friday, 5:00 am – 3:00 pm Pacific.

Gravel Stabilizer Grid FAQs

Should I use geocell panels or a roll-form paver?

Geocell panels where you need selectable depth — heavier vehicles, soft subgrade, slopes, or anywhere deep confinement is the point. Roll-form pavers where the loads are cars and light trucks, the area is large, install speed matters and the surface has to be plowable.

What geocell depth do I need?

3″ for light duty gravel, footpaths and garden access. 4″ is where most residential gravel drives land. 6″ for heavier vehicles, access roads and softer subgrade. 8″ for machinery and the worst ground conditions.

Do I still need base aggregate?

Usually yes, but less of it. The grid does not replace aggregate, it makes aggregate work harder by confining it. Because the confined layer spreads load properly, the same performance generally takes less depth than loose gravel would.

What kind of gravel should I use?

Angular crushed stone. Angular material interlocks and stays put once confined. Rounded pea gravel behaves like ball bearings and works loose regardless of what is holding it, so it is the wrong fill for any stabilizer system.

Will the grid be visible?

Not once it is filled and topped off. Both systems finish with a thin layer of aggregate over the grid so the surface reads as gravel. The roll-form pavers additionally come in four colors so any exposure blends with the stone.

Can I plow it in winter?

The NDS EZ Roll gravel pavers are plowable. With geocell, keep the blade high enough to clear the top of the cells — the grid sits below the finished surface, but a blade set low will find it.

Does water still drain through?

Yes. Both systems stay fully permeable, which is a large part of why they are specified over hard paving on driveways and parking areas.

How much do I need?

Work out the area in square feet and divide by the coverage per unit — 179.76 sq ft per EnviroGrid panel, 180 per Cell-Tek panel, 577 per EZ Roll. Add a little for cuts around edges and obstacles.

Will it work on a slope?

Geocell is the better choice on any real gradient, because the cell walls physically resist aggregate sliding downhill. Deeper cells hold more securely on steeper ground.

What does shipping cost?

Nothing. Shipping is free on every order, on all depths, colors and quantities.
